Barco C-5 Wireless Presentation System, App-controlled, Seamless collaboration, Simple one-click experience - R9861505EU

Barco C-5 Wireless Presentation System, App-controlled, Seamless collaboration, Simple one-click experience - R9861505EU

Product Highlights

• Boost collaboration: ClickShare C-5 enables one-click wireless screen sharing in Microsoft Teams, Zoom, or Webex for hybrid meetings.
• Easy content sharing: Share content wirelessly in full HD using the ClickShare App on any device.
• Intuitive design: ClickShare C-5 supports BYOD, 4K display, and screen mirroring with Airplay, GoogleCast, and Miracast.
• Seamless integration: Designed for enterprise rollouts, ClickShare C-5 offers enhanced security and remote management.
• Barco ClickShare: Revolutionize collaboration with intuitive click-and-share functionality.

Specifications

ClickShare Base Unit dimensions:
Dimensions (HxWxD): 34 mm x 135 mm x 135 mm
Power supply: Standard 110/220 V AC plug or USB-C (only Gen2)
Power consumption: Operational: 5-10W, 24W Max
Weight: 900 gr
General specifications:
Operating system:
Windows 10 and higher
macOS 11 (Big Sur) and higher
Android v9 and higher (ClickShare App)
iOS 12 and higher (ClickShare App)
Video outputs: 4K UHD (3840*2160) @ 30Hz. HDMI 1.4b or USB-C DisplayPort 1.2 (only Gen2)
Audio output: HDMI
USB: 1 X USB-A, 1 X USB-C
ClickShare Buttons: 0
ClickShare App: Desktop & Mobile
Native protocols: Airplay, Google Cast, Miracast
Maximum number of simultaneous connections (with Buttons and/or App): 32
Noise Level:
Max. 25dBA @ 0-30°C
Max. 30dBA @ 30-40°C
Authentication protocol:
WPA2-PSK in stand-alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
Wireless transmission protocol: IEEE 802.11 a/g/n/ac and IEEE 802.15.1
Reach: Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
Frequency band: 2.4 GHZ and 5 GHz (DFS channels supported in select number of countries)
Connections:
1x Ethernet LAN 1Gbi
1x USB-C 2.0 (front); 1x USB-A 2.0 (front) - only Gen2: 1x USB-C 3.0 (front); 1x USB-A 3.0 (front)
Temperature range:
Operating: 0°C to +40°C (+32°F to +104°F)
Max: 35°C (95°F) at 3000m
Storage: -20°C to +60°C (-4°F to +140°F)
Humidity:
Storage: 0 to 90% relative humidity, non-condensing
Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system: Kensington lock
Certifications: FCC/CE
Touch screen support & Interactivity: /
Room Dock (peripheral support): No
Local view: Local view of the room display only
Network connection: LAN & WiFi
Management and reporting: Yes
Warranty: 1 year standard. 5 years coverage via SmartCare  depends on configuration, available in future firmware updates
