Yeastar NeoGate TG400 4 POrts GSM VoIP Gateway
Yeastar NeoGate TG400 4 POrts GSM VoIP Gateway
Product Highlights
- Cost savings: Save on phone bills with mobile-to-mobile calls and Least Cost Routing (LCR).
- Backup solution: Serve as a cost-effective backup when the landline network is unavailable.
- Easy installation: Simple setup through the web-based management interface.
- Integration: High compatibility with major IP PBX and softswitch brands.
- SIP support: Compatible with SIP servers, SIP trunks, and SIP peer mode.
- Calling types: Supports VoIP to GSM and GSM to VoIP calls.
- Port and trunk management: Manage GSM ports and VoIP trunk groups.
- Open API protocol: Supports real Open API protocol based on Asterisk.
- Security features: Includes IP blacklist, network attack alert, and system logs.
Specifications
Number of Ports 4
GSM Frequency 850/900/1800/1900 MHz
WCDMA Frequency 850/1900 MHz, 850/2100 MHz, 900/2100 MHz
4G LTE Band Depending on the module type.
Protocol SIP, IAX2
Antenna Splitter (4 in 1) Support
Voice Codec G.711 (alaw/ulaw), G.726, G.729A, GSM, ADPCM, Speex
DTMF Mode RFC2833, SIP Info, In-band
Echo Cancellation ITU-T G.168 LEC
Calling Type Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP)
Network Protocol FTP, TFTP, HTTP, SSH
LAN 1 10/100 Mbps Ethernet Interface
NAT Traversal Static NAT, STUN
Network DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN
Operation Range 0°C to 40°C, 32°F to 104°F
Power Supply AC 100-240V
Storage Range -20°C to 65°C, -4°F to 149°F
Humidity 10-90% non-condensing
